56 road controller

Signal function characteristics:

1. With Motorola32 a high-performance microcontroller as the core.

2. Modular design, installation and maintenance is convenient.

3. Using solid-state switch control signals, running stability.

4. Safety yellow ShanQi unit operation for independence.

5. With the help of reliable microprocessor, toroidal coil detector system.

6. Through flexible convenient communication interface to connect the control center, the system can be coordinated control.

7. A variety of communication interface: RS - 232/485.

8. The power input has a power surge and lightning prevention measures.

9. The electric leakage protection function.

10. Signal embedded software running environment using real-time multitasking operating system, guarantee system is stable and reliable.

11. The detector, the working state of the peripheral equipment such as communication, lamps and lanterns of automatic monitoring and records, failure automatic alarm and automatically take the corresponding treatment measures.

12. We have the light color of green conflict monitoring.

13. Can use GPS timing way to ensure the accuracy of system clock.

14. Comprehensive fault diagnosis function makes the fault location is relatively easy.

15. To generate the feature parameters and being easy to download, can use PC (laptop) or PDA.

16. Acquisition function: the function of the traffic flow information collection and processing;

17. Storage functions: storage function of traffic information such as;

Signal I/O metrics:

1) drive 8 phase plate, 32 phase drive, 96 lamp control terminals

(2) 32 vehicle detector coil detector)

3) 8 road pedestrian button

4) 8 road bike detector

5) reserved six switch input interface, and seven switch output interface

6) 8 road relay output

Electrical signal indicators:

1) power supply: AC220V + 44 v, 50 hz plus or minus 2 hz

2) driving power: 800 w

3) the machine power consumption: 50 w

4) more than 10 m Ω insulation resistance

5) pressure

6) electromagnetic  immunity
